calculate the angles from bearings

There are two systems of mention of bearings.

A. Whole Circle System:- In the whole circle system the bearing of a line measured from the north point of the reference meridian to the line in a clockwise direction.

It has an angle between 0° to 360°.

It has an angle between 0° to 360°.

whole circle bearing |

In the figure, the whole circle bearing is 240° from the north.

SEE MORE

B.Quadrantal System:-In the quadrant system the bearing of a line is measured clockwise or counterclockwise from the north point or south point. Toward the east or west direction. It has an angle between 0°to90°.

Quadrant bearing |

In the above picture, the line AB falls in the I quadrant. AC is in the ii quadrants, AD in iii quadrants, AE in the iv quadrants, The angle making of these lines from north and south is called reduced bearing.

In the above picture reduced bearing AB=N30E°, AC=S40°E, AD=S30°W, AE=N25°W.

Method of Calculation quadrant bearing see also:-

fore bearing and back bearing |

Fore and Back Bearing:- Every line has two bearings. The bearing of a line in the direction of the progress of the survey is called the fore or forward bearing and the bearing of the opposite direction is known as the back or reverse bearing(B.B)

Back bearing= Fore bearing (+),(-) 180°.

In the quadrantal system, the fore and back bearing are numerically equal but with opposite quadrant systems.

If the fore bearing AB line is N 40° E, then the back bearing of the line AB is S 40° W.

Back bearing= Fore bearing (+),(-) 180°.

In the quadrantal system, the fore and back bearing are numerically equal but with opposite quadrant systems.

If the fore bearing AB line is N 40° E, then the back bearing of the line AB is S 40° W.

Calculation of angles from bearing

Case l:-Given the whole

circle bearing of lines.

Subtract smaller angles from the greater. The difference will give the interior angle if it is less than 180°. If the difference exceeds 180°, It will be the exterior angle. Obtain the interior by subtracting the difference from 360°.

If any lines AB,41°, AC, 115 °

Angle BAC= Bearing of AC-Bearing of AB=115°-41°=74°.

Case ll:- Given the reduced bearing of Lines:

A |

(a) if the lines are on the same side of the same meridian. See above picture

Included angle= difference of the bearing of OA and OB.

B |

(b) if the lines are on the same side of the different meridians, included angle=180°-sum of the two reduced bearings.

C |

(C) if the lines are on different sides of the different meridian.

Included angle=180°-difference of the two reduced bearings.

BOA=180°-difference of the bearing OB and OA.

D |

(d) if the lines are on opposite sides of the same meridian.

The included angle= sum of the two reduced bearings.

BOA= sum of the bearings of OB and OA.
